Neutrik NAC3FXXA-W-S Powercon Connector, Locking AC Mains, 3 Conductor, Screw Terminal, Grey

Neutrik NAC3FXX Powercon Connectors

Designed for professionals requiring a robust and secure power connection, the Neutrik NAC3FXX Powercon Connectors offer a reliable solution for high-demand environments. This locking AC mains cable connector is ideal for replacing traditional appliance couplers, providing a rugged and dependable connection with its twist-lock system. Its keyed and colour-coded design prevents intermating, ensuring a safe and secure power-out connection. The product benefits from superior Neutrik quality, making it an excellent choice for users who prioritise reliability and performance in their power solutions.

Technically advanced, the Neutrik NAC3FXX Powercon Connectors come with screw terminal assembly suitable for cable diameters ranging from 6 to 12mm and 10 to 16mm. This single-phase (3 conductor) lockable power connector showcases circuit-breaking capability when used with Powercon XX Series receptacles. With a contact resistance of ≤ 2 mΩ and a typical lifetime of 5,000 mating cycles, this connector ensures long-term performance. Operating within a temperature range of minus 33 Degrees to plus 80 Degrees and holding an IP20 rating, the Neutrik NAC3FXX promises durability in various conditions.
