Mercury Eco RG6 Coaxial Cable, 75 Ohm, Air Spaced PE, CCA Braid, 100m, White

Mercury Economy RG6 75 Ohms Air Spaced Coaxial Cable

This Mercury Economy RG6 coaxial cable is crafted for reliability and efficiency in digital, satellite, and cable TV signal transmissions. Its solid copper-clad steel conductor, coupled with an air-spaced polyethylene dielectric, ensures high signal integrity while minimising noise penetration. Ideal for both domestic and commercial use, this cable is a dependable solution for quality broadcast transmission. The aluminium foil screen and copper-clad aluminium braid enhance its shielding capabilities, making it an excellent choice for installations where interference is a concern. Supplied in a 100-metre reel, this cable is practical for various installation requirements, offering flexibility and ease of use.

Technically, the Mercury Economy RG6 coaxial cable features a 1mm diameter solid CCS conductor with a cable diameter of 6.6mm. The air-spaced polyethylene dielectric has a diameter of 4.6mm. The cable has an impedance of 75 Ohms with a capacitance of 54pF/m and a velocity factor of 83%. It weighs 4.2kg and is marked with metric cut markers for precision in installations. The cable offers substantial return loss across frequencies and minimal attenuation, making it suitable for high-performance signals. The braid material is made of CCA, ensuring durability while maintaining effective performance.
